Morel Virtus Nano MW4 – Premium Ultra-Slim 4″ Woofer Driver
Experience Morel’s philosophy that rejects one-size-fits-all approaches with precision-engineered ultra-slim woofer technology designed for custom component applications.
Product Overview
The Morel Virtus Nano MW4 represents innovative ultra-slim woofer technology, developed from Morel’s philosophy that rejects one-size-fits-all approaches in favor of specialized engineering solutions. This precision-crafted 4″ woofer features advanced carbon cone construction with foam core technology, delivering exceptional frequency response from 80-9200 Hz while maintaining only 17mm (0.7″) mounting depth. The sophisticated design incorporates a 54mm Hexatech™ aluminum voice coil with aluminum former, paired with a vented neodymium magnet system that provides remarkable 90W RMS power handling and 88dB sensitivity. The carbon cone material offers optimal mass-to-stiffness ratio with superior damping characteristics, while the ±3mm linear excursion capability ensures accurate reproduction across the woofer’s frequency range. With carefully engineered Thiele-Small parameters including 95Hz resonant frequency and optimized Q factors, the MW4 delivers exceptional performance in compact enclosures. The ultra-shallow profile makes it ideal for space-constrained installations where traditional woofers cannot fit. Perfect for Australian drivers building custom component systems, motorcycle applications, or specialized automotive installations where ultra-compact mounting depth and exceptional mid-bass performance are essential for professional-quality sound reproduction.
Specifications
| Model | Virtus Nano MW4 |
|---|---|
| Nominal Impedance (ohm) | 4 |
| Power Handling Wrms | 90 |
| Max. Trans. Pwr Handling Wrms | 300 |
| Sensitivity (2.83 V/1M) dB | 88 |
| Frequency response Hz | 80-9200 |
| Resonant Freq. Fs Hz | 95 |
| Voice Coil Diameter mm (inch) | 54 (2.16) |
| Voice Coil Height mm (inch) | 9 (0.35) |
| Voice Coil Type/Former | Aluminium |
| Voice Coil Wire | Hexatech™ Aluminium |
| DC Resistance (ohm) | 3 |
| Voice Coil Induct. @1 kHz (mH) | 0.12 |
| Magnet System | Neodymium Vented |
| BL Product/BXL | 4.68 |
| Max. Linear Ex./Xmax mm (inch) | ±3mm (0.12) |
| Electrical Q Factor QES | 0.7 |
| QTS | 0.6 |
| QMS | 4.01 |
| Moving Mass MMS – gr/ounce | 8.57 (0.3) |
| Equiv. Can Air Load VAS – L (cu.ft3) | 1.48 (0.05) |
| Effective Piston Area SD sq.cm (sq.inch) | 57(8.8) |
| Cone Type | Carbon Cone |
| Cone Material | Carbon + Foam Core |
| Unit Diameter mm(inch) | 109 (4.3) |
| Mounting Depth mm (inch) | 17(0.7) |
| Mounting Cutout | 93 (3.6) |
| Net Weight gr | 376 |
