Dedicated to the Highest-Performing Prima Systems!
Prima Line – Subwoofer Box (APBX 10 DS)
The APBX 10 DS, a 10″ subwoofer loaded in a 12 – litres sealed enclosure, is the line’s flagship. It is dedicated to the highest-performing Prima systems, using the AP1 D amplifier for the sub-section. The speaker’s mechanical excursion of more than 18 mm provides for incredible authority, while the refined Thiele & Small parameters setup provides the ideal balance for all music genres.
Features:
- Ultra-low profile (5.6 in. / 142 mm) box with a sealed design perfectly tuned to fully exploit the APS 10 D driver.
- 2S2 (2 Sides/2 Sounds) design provides the ability to choose between down-firing mounting to increase the low-frequency extension and Up-firing install to obtain more punch and definition.
- Leveling feet with velcro inserts included for a secure grip on the carpet while maintaining easy removal.
- SSP (Sub Smart Plug) features both traditional push contacts and a Plug-&-Play terminal block to easily configure the impedance as required and provides a quick release.
- Rounded corners allow easy positioning in the trunk and act as reinforcement to reduce enclosure resonance.
- Specially designed cone-dust cap-basket geometry which guarantees a long linear excursion capability (11 mm, one-way).
- Massive driver motor assembly, optimized with FEM (Finite Element Modelling) for perfect control under high excursion conditions.
- Water-repellent pressed paper 10 in. cone, featuring a profile developed with FEM simulation and optimized with the Klippel Scan Vibrometer.
- A sturdy metal grid is included for total protection of the subwoofer driver.
Specifications:
- Component: Passive Sealed Sub Box
- Subwoofer Size: 250mm (10″)
- Power Handling – Peak: 800W
- Power Handling – Continuous: 400W
- Impedance: 4 + 4Ω
- Sub Box Size: 470mm x 142mm x 334mm (18.5″ x 5.59″ x 13.15″)
- Magnet: High-Density Flux Ferrite
- Cone: Water-Repellent Pressed Paper
- Subwoofer Voice Coil: 60mm (2.36″)
- Packaging Type: Giftbox
- Weight: 8.63kg
